Proxima Power Proxima Probe 10 · REV A · PRE‑RELEASE Get Notified

Early access · first production run

Measure gain and phase to 10 MHz. Drive it with a built in 100 MHz AWG.

A frequency response analyzer and arbitrary waveform generator in one compact instrument. Measure control loops, characterize components, sweep impedance. Integrated isolation, no injection transformer required.

$999 Launch price
Get Notified →

We'll email you once it's ready to ship. AWG = Arbitrary Waveform Generator

LOOP GAIN · BUCK CONVERTER 100Hz – 10MHz Sweep
GAIN dB 60 30 0 −30 −60 fc 50 kHz PHASE ° −60 −90 −120 −150 −180 PM 85° 100 1k 10k 100k 1M 10M FREQUENCY Hz

The instrument

§ 1
The Proxima Probe 10 frequency response analyzer: a black extruded-aluminium instrument in blue end bezels, with OUT, CH1 and CH2 BNC connectors on the front panel.
Proxima Probe 10 — Compact size saves bench space.
ARB OUT · PROGRAMMED SWEEP 20Vpp @ 50Ω
SINE TRIANGLE RAMP SQUARE 66% 100% Includes AM, FM, PWM Modulation at Launch
Function or arbitrary waveform capability.

Specifications

§ 2
ParameterValueNotes
FRA Range 0 – 10MHz Gain-phase sweep from 10 µHz (DC) — control loops, component characterization, impedance and filters.
AWG Bandwidth 100 MHz Sine Full feature independent arbitrary waveform generation, not a limited function generator.
AWG Output 20Vpp @ 50Ω Enough drive to excite real hardware directly, not just small-signal inputs.
Isolation 400 VRMS No injection transformer required means no rolloff at low frequencies.
Launch price $999 USD Dedicated gain-phase analyzers start in the thousands without an AWG.
Assembly Los Angeles We wanted one, so we built it!
Status Pre-release Final development and testing. Release 2027.

Reserve a unit

§ 3

Get on the list

Early access and launch pricing on the first production run.

  • No payment required to join
  • One email when units ship
  • First-run pricing locked in at signup

Proxima Power is revolutionizing test equipment by combining features for greater functionality and lower pricing.
